Three Channel Micro Hand Transmitter – Digital 313

Marantec garage door remote

Three Channel Micro Hand Transmitter – Digital 313

  • Digital 313
  • Three Channel
  • 433MHz Multibit
  • Micro Hand Transmitter

Available

SKU: MAH9594 Categories: , ,
  • Description
  • Additional Technical Information

Description

Digital 313 – Three Channel 433MHz Micro Hand Transmitter

Digital 313 – 433MHz

  • Micro hand transmitter, 3-channel
  • 433MHz Multibit

Package contents

  • Micro hand transmitter, 3-channel
  • 3 V button cell, CR2032
  • Coding plug
  • Key ring

Function/application

  • Impulse for door Open/door Close
  • For all Marantec operator systems and operator systems from other manufacturers (In combination with the respective Digital receiver)
  • To control maximum three operator systems



Technical details/specifications

  • Measurements (WxHxD): 34 x 50 x 12 mm
  • Nominal voltage: 3 V button cell. CR 2032
  • Protection category: IP 54
  • Range of temperature: -20ºC to +60ºC
  • Operation control: LED
  • Coding possibilities: > 281 trillions

Programming Guide

PLEASE NOTE:  When adding a new style 433MHz remote for use with existing old style 433MHz remotes an "old to new style" handset programming lead is required if you need to copy the encrypted code from  old to new type handsets - See final listing in this section.
