Chamberlain Liftmaster LM750 MYQ Kit

LM750EVGB MYQ ‘Connected’ Package includes:



  • LM750EVGB MyQ Enabled Roller Door Operator
  • TX4EVS Two 4 Channel Remote Controls
  • 128EV Wireless Wall Control
  • 828EV Internet Gateway
  • G771EVK Safety Sensors
  • Description
  • Features
  • Additional Technical Information
  • Downloads

Description

Chamberlain Liftmaster MyQ Kit
– Internet Connected –

Great smart solution for your rolling garage doors!

The LM750EVGB, with MyQ technology, completes the family of MyQ enabled operators. For the first time, a rolling garage door operator can now be connected to the internet using the MyQ internet gateway 828EV.
(IR sensors 770E or 771EVK must be installed to use MyQ enabled operators)

Monitoring and control of the garage door is possible via smartphone or tablet using the MyQ App.

LM750EVGB MYQ ‘Connected’ Package
includes:

Chamberlain Liftmaster LM750 roller garage door opener
Chamberlain Liftmaster LM750EVGB MyQ Enabled Roller Door Operator
Chamberlain Liftmaster TX4EVS garage door remote
Chamberlain Liftmaster TX4EVS Two 4 Channel Remote Controls
Chamberlain Liftmaster 128EV Wireless Wall Control
Chamberlain Liftmaster 128EV Wireless Wall Control
Chamberlain Liftmaster MyQ 828EV Internet Gateway
Chamberlain Liftmaster MyQ 828EV Internet Gateway
Chamberlain Liftmaster Infrared Safety Senor Kit
Chamberlain Liftmaster G771EVK Safety Sensors

Chamberlain Liftmaster LM750 Automatic Roller Garage Door Operator – Opener Supersedes the models LM650 and RDO800.

This new garage door opener from Chamberlain Liftmaster exclusively suits residential roller curtain garage doors. The motor unit is mounted directly to the existing roll shaft and a forked device engages with the spoked wheel within the roll to provide the motion. For single, double car domestic and light industrial roller doors.

Chamberlain MYQ Stay connected with MyQ
With MyQ, you can monitor and control your garage door, using your smartphone, tablet or computer from wherever you happen to be.
Chamberlain smart radio technology Smart radio technology
Evolution operators are equipped with the best reliable radio that is a bi-directional radio. They don't only receive signal, they also sends signals back.
Chamberlain 5 years motor warranty Up to 5 years motor warranty
The long-time warranty demonstrates that LiftMaster provides premium quality products.
Chamberlain long-lasting LEDs Long-lasting LEDs
Immediate brightness, low CO2 emissions and avoidance of heavy metals and mercury in manufacturing.
Chamberlain quickly installed Quickly installed
Simple installation with standard tools.

Features:

  • Includes two 4 channel remotes
  • Comes with 2 button wireless wall control
  • Quiet & powerful DC motor, only 59db
  • Soft start and soft stop
  • Self-locking gear system when garage door is closed
  • For single, double car domestic and light industrial roller doors
  • Long range encrypted radio technology
  • Energy saving with low standby power
  • Electronic never forgetting travel distance limits
  • Automatic operating force adjustment for UP and DOWN travel
  • Meets or exceeds international safety standards including SASO
  • Manual disconnect system in case of power failure
  • LED lighting
  • 5-Year Motor Warranty
  • 2-Year Warranty on all other items
  • TÜV-tested to meet EN12453
  • For doors up to 120kg / 18m²
SPECIFICATION LM750EVGB
Input voltage 220 - 240Vac, 50 - 60 Hz
Motor voltage 12VDC
Transformer rating 80VA
Drive system Direct drive
Standby power 0.8 Watt
Pulling force 550N
Watts 110 Watts
Rated load ( Torque ) 25Nm
Overload protection Yes
Temperature range Minus 25 / plus 55 celcius
Installation orientation Left or right hand side (limits)
Extension poles for deep reach Yes x 2
Rated door area 18m²
Max door height 4.5 meter
Max door weight 120Kg
Min side room 45mm
Standard side room 95mm
Max. door axle diameter 35mm
Travel speed 13 seconds (2.3 high)
Number of drum rotations 4 1/2
Noise 59dBA
Radio EVO 433.92MHz rolling code
Number of memory registrations 64
Radio signal range Up to 160 meters (free field)
Lighting 6 LEDs, ultra bright, 150 secs
Safety Auto reverse
Auto close ( IRs req'd ) Yes, 1 min, 5 min or 10 min
Soft start / stop Yes
Automatic limit & force setting Yes
Diagnostic LED system Yes
Warranty - drive motor 5 years
Warranty - other items 2 years
Certification TUV
Accessory output No
Internal release device Yes
Water - resistant rating n/a
Maintenance counter no

Supplied with full instructions in English and a British 13amp 3-PIN plug.
