Chamberlain Liftmaster LM750 Roller Door Opener
For single, double car domestic and light industrial roller doors
- Additional Technical Information
Chamberlain Liftmaster LM750 Automatic Roller Garage Door Operator – Opener Supersedes the models LM650 and RDO800
This new garage door opener from Liftmaster exclusively suits residential roller curtain garage doors. The motor unit is mounted directly to the existing roll shaft and a forked device engages with the spoked wheel within the roll to provide the motion.
|Stay connected with MyQ
With MyQ, you can monitor and control your garage door, using your smartphone, tablet or computer from wherever you happen to be.
|Smart radio technology
Evolution operators are equipped with the best reliable radio that is a bi-directional radio. They don't only receive signal, they also sends signals back.
|Up to 5 years motor warranty
The long-time warranty demonstrates that LiftMaster provides premium quality products.
Immediate brightness, low CO2 emissions and avoidance of heavy metals and mercury in manufacturing.
Simple installation with standard tools.
- Includes two 4 channel remotes
- Comes with 2 button wireless wall control
- Quiet & powerful DC motor, only 59db
- Soft start and soft stop
- Self-locking gear system when garage door is closed
- For single, double car domestic and light industrial roller doors
- Long range encrypted radio technology
- Energy saving with low standby power
- Electronic never forgetting travel distance limits
- Automatic operating force adjustment for UP and DOWN travel
- Meets or exceeds international safety standards including SASO
- Manual disconnect system in case of power failure
- LED lighting
- 5-Year Motor Warranty
- 2-Year Warranty on all other items
- TÜV-tested to meet EN12453
- For doors up to 120kg / 18m²
|Input voltage||220 - 240Vac, 50 - 60 Hz|
|Drive system||Direct drive|
|Standby power||0.8 Watt|
|Rated load ( Torque )||25Nm|
|Temperature range||Minus 25 / plus 55 Celsius|
|Installation orientation||Left or right hand side (limits)|
|Extension poles for deep reach||Yes x 2|
|Rated door area||18m²|
|Max door height||4.5 meter|
|Max door weight||120kg|
|Min side room||45mm|
|Standard side room||95mm|
|Max door axle diameter||35mm|
|Travel speed||13 seconds (2.3 high)|
|Number of drum rotations||4 1/2|
|Radio||EVO 433.92MHz rolling code|
|Number of memory registrations||64|
|Radio signal range||Up to 160 meters (free field)|
|Lighting||6 LEDs, ultra bright, 150 secs|
|Auto close ( IRs req'd )||Yes, 1 min, 5 min or 10 min|
|Soft start / stop||Yes|
|Automatic limit & force setting||Yes|
|Diagnostic LED system||Yes|
|Warranty - drive motor||5 years|
|Warranty - other items||2 years|
|Internal release device||Yes|
|Water - resistant rating||n/a|
Supplied with full instructions in English and a British 13amp 3-PIN plug.
