Marantec Digital 572 – Two Channel 868MHz Bi-Linked Micro Hand Transmitter

Marantec D572 garage door remote
MAH9920

Marantec Digital 572 – Two Channel 868MHz Bi-Linked Micro Hand Transmitter

  • 2 function buttons for free configuration
  • Electronic button lock programmable
  • For all Marantec opener systems – series 200 models 260/270/280 and series 300 models 360/370/380 (and other’s opener systems in combination with the respective bi·linked receiver)
SKU: MAH9920 Categories: , , ,
  • Description
  • Features
  • Downloads

Description

Digital 572 – Bi-Linked 868MHz

  • Micro hand transmitter 2-channel
  • 868MHz

Package contents

  • Micro hand transmitter 2-channel
  • 3 V button cell. CR 2032

Function/application

  • Impulse for door Open/door Close
  • For all Marantec operator systems (series 200 models 260/270/280 and series 300 models 360/370/380) and operator systems from other manufacturers (In combination with the respective bi·linked Digital receiver)
  • To control maximum two operator systems

Technical details/specifications

  • Measurements (WxHxD): 39 x 60 x 12 mm
  • Nominal voltage: 3 V button cell. CR 2032
  • Range of temperature: -20ºC to +60ºC
  • Operation control: LED

Marantec bi·linked radio technology:
Safe. Simple. Clever.

Efficient – bi.linked

Bi·linked reliably opens and closes your doors at the push of a button. It can also communicate with you. By simple pressing the status button, bi·linked will let you know with its LED indicator whether your door is open or closed – whenever you are out of sight. Bi·linked is available as uni-directional and bi-directional version, i.e. with and without communication.

Straightforward – bi·linked

Thanks to the fact that bi·linked is wireless, there is no need for any cables between the individual devices. It also means that you can fit your accessories wherever they are most convenient for you and upgrade them at any time if your needs change. All of the current Marantec garage door openers can communicate with our bi·linked accessories.

Secure – bi·linked

Next to comfort, security is always top of Marantec's list. This is why the wireless bi·linked radio technology works with 128-bit encryption, which is the same key as is used in online banking. At the same time, it also uses a rolling code, which means that it transmits a different code to the opener every time the opening button is pressed, which makes it near impossible for the code to be copied or decoded. The transmitter is also highly resistant to interference and does not interfere with other wireless devices nearby.

Modern – bi·linked

The Marantec Digital 633 bi·linked hand transmitter is not only extremely safe and comfortable to use, but is also a very sophisticated design object. A winner of the highly renowned international
Red Dot Design Award, it will add an extra dimension to the simple act of opening your garage door.
